P3.91-7.81 Transparent AVOE LED Display For Building Glass Wall
Lightweight for American market
Transparent LED Display is no doubt the best choice as windows ads
player, without sacrifice ventilate and natural light with the
48%~90% transparency, you won’t miss any view from it. Transparent
AVOE LED Display is ultra slim and thin, easy for installation and
transportation, time and labor efficient. The quick lock system of
Transparent LED Display secured quick and fast connection.
Integrated power and data cables save lots of trouble when
installing Transparent LED Display and make it looks tidy and
elegant. Transparent LED Display can only be installed indoors, but
also view-able from outside of the building, high brightness and
high definition making a stunning effect of your ads to passers.
Transparent LED Display possesses transparent and modern product
aesthetics which can benefit to installation over windows, glass
facade and for creative event production as well. It is lightweight
and ultra-thin, making deployment a breeze. High transparency
guarantees natural view behind the screen while delivering clear
and crisp contents view-able for both day and night.
Parameters
| Model | P3.91 | P3.91 | P7.81 | P7.81 | P10.4 |
| Pixel pitch | 3.91-7.81 | 3.91-7.82 | 7.81 | 7.81-15.625 | 10.4 |
| Lamp | Indoor SMD2121 | Outdoor SMD1921 | Outdoor SMD2525 | Outdoor SMD2525 | Outdoor SMD2525 |
| Pixel density | 32768 | 32768 | 16384 | 8192 | 9230 |
| Module size | 500mm*500 or500mm*1000mm or1000mm*1000mm Can be Customized Size
available |
| Cabinet material | Acryic Aluminum Steel |
| weight | 15KG/㎡ | 15KG/㎡ | 14KG/㎡ | 14KG/㎡ | 14KG/㎡ |
| Transparency | 65% | 65% | 70% | 75% | 80% |
| Brightness | ≥1000nit | ≥4500nit | ≥4500nit | ≥4500nit | ≥4000nit |
| Refresh rate | ≥1920HZ |
| Scan mode | 1/165 | 1/85 | 1/25 | 1/25 | 1/35 |
| Max power consumption | 400W/㎡ | 600W/㎡ | 600W/㎡ | 550W/㎡ | 550W/㎡ |
| Average power | 120W/㎡ | 180W/㎡ | 180W/㎡ | 180W/㎡ | 180W/㎡ |
| PCB | FR-4 four layers board,2.0mm thickness |
| Driver IC | MBI5124,Hight Refresh Rate |
| Installation | Hanging or Stacking |
| Brightness level | 256 Level |
Features
1. Total clear body ensures stage lights go through easily
2. Single-person handling, easy transportation for touring shows
3. High transparency rate: it is as high as 70%. Led lights are
almost invisible from a specific distance
4. Simple installation: can be directly installed behind the glass
5. Light-weighted with 9kg/panel, perfectly applied for mobile
shows and rental applications
6. Standard Module Size
Standard size can be used to assemble larger DispLays, using The
right resolution for The job
7. Best seLLing product model with high brightness and resolution,
highly customizabLe.
Application
AVOE LED Transparent Glass Curtain Wall LED Display (TGC series)
for building glass wall, Auto 4S shop,
high-end clothing stores, retail windows, stage rental, et
Detailed Pictures
AVOE LED Competitive Advantages:
1. Good quality;
2. Good price;
3. Good 24hours service;
4. Promote delivery;
5. Energy-saving;
6. Small order accepted.
Our serrvices
1. Service before sales
On-site inspect
Professional design
Solution confirmation
Training before operation
Software use
Safe operation
Equipments maintenance
Installation debugging
Installation guidance
On-site debugging
Delivery Confirmation
2. After sale service
Quick response
Prompt question resolving
Service tracing
3. Service concept:
Timeliness, considerateness, integrity, satisfaction service.
We are always insisting on our service concept, and proud of the
trust and reputation from our clients.
4. Service Mission
Answer any question; Deal with all the complaint; Prompt customer
service
We had developed our service organization by responding to and
meeting the diverse and demanding needs of customers by service
mission. We had become a cost-effective, highly skilled service
organization.
5. Service Goal:
What you have thought about is what we need to do well; We must and
will do our best to fulfill our promise. We always bear this
service goal in mind. We can't boast the best, yet we will do our
best to free customers from worries. When you get problems, we had
already put forward solutions before you.
