IP65/IP43 Outdoor Programmable Led Signs / Large Led Video Screens
Solid & Light
Perimeter LED Screen Main Features :
1. Portable die-casting Aluminum design of the panel,easy to
install or disassemble.
2. Creative innovations to replace traditional IRON structure
outdoor permanent LED screen With one more holder to hold up the
screen, it can be widely used for outdoor applications.
3. Solid & light;
The cabinet is made of aluminum die-casting, very strong and light,
only 35kg/sqm, while normal iron cabinet is 55kg/sqm;
4. Unique aluminum module frame, good for heat sink;
5. Multi-function display;
The back bracket is removable, means that you can easily take off
bracket in 3 seconds, then it turns normal display for fixed
installation or rental business;
6. Different pitch display share one same cabinet frame;
pitch 2.6mm, 3.2mm, 5.33mm, 6.4mm, 8mm, 10.66mm, 12.8mm, 16mm share
one cabinet frame of 1024*768mm, in case in future of update, you
only need to change modules, so it helps you save money;
7. Easy maintenance;
Front access module is available, so you can take off module
easily;
Pure white color display always available, due to we use top rate
Leds;
Specification
| Indoor / Outdoor PM | IPM6 | IPM10 | OPM8 | OPM10 | OPM16 |
| Pixel Pitch(mm) | 6 | 10 | 8 | 10 | 16 |
| Pixel Matrix Per Sq.m | 27777 | 10000 | 15625 | 10000 | 3906 |
| Pixel Configuration | SMD3528 | SMD3528 | SMD3535 | SMD3535 | SMD3535 |
| Brightness (nits) | 2200 | 1800 | 6800 | 7500 | 8000 |
| Scan | 1/8 | 1/4 | 1/3 | 1/2 | 1/1 |
| Module Dimension | 192x192mm/0.63x0.63ft | 320x160mm/1.05x0.52ft | 320x160mm/1.05x0.52ft | 320x160mm/1.05x0.52ft | 256x256mm/0.84x0.84ft |
| Cabinet Dimension | 960x960mm/3.15x3.15ft | 1280x960mm/4.2x3.15ft | 1280x960mm/4.2x3.15ft | 1280x960mm/4.2x3.15ft | 1024x1024mm/3.36x3.36ft |
| Cabinet Resolution | 160x160 | 128x96 | 160x120 | 128x96 | 64x64 |
| Cabinet Weight | 40kg / 88Ib (Iron) | 44kg / 97Ib (Iron) | 49kg / 108Ib (Iron) | 48kg / 105Ib (Iron) | 46kg / 101Ib (Iron) |
| Power Con. (Max / Avg) | 550 / 100 w/sq.m | 500 / 90 w/sq.m | 680 / 120 w/sq.m | 650 / 110 w/sq.m | 690 / 130 w/sq.m |
| IP Rate | IP43 | IP65 |
| Service Access | Front / Rear | Front / Rear |
| Refresh Rate (HZ) | 2880 | ≥2880 |
| Grey Scale (bit) | 14bit | 16bit |
| Viewing Angle (H/V) | 140 / 140 | 140 / 140 |
| Input Voltage (AC) | 110V / 240V | 110V / 240V |
Detailed:
Solid, Compact, Strong Cabinet Design For All Weather and Prevent
for Any External Attacks
Rotating Design with Wheels for Emergency Exit
PM series with rotating base and wheels for emergency exit for
perimeter LED display installation in stadium.
This is necessary for quick and easy escape required by most
football associations.
Adjustable Bracket
Cabinet adjustable angle between 60°and 90°
Protective Top Cover and Rubber Module Mask
Protective top cover protect players from injury. Rubber module
mask protect LED from ball and players striking,
besides protect players against further injury.
Independent RCD Protection
RCDs protect the system against short circuits, overcurrent and
leakage currents which makes the system absolutely safe to operate.
Professional Software PM Player
PM Player and software makes it easy to control your screen,
manage your media and show linear content on your perimeter LED
display, which is friendly for advertising application.
4H Makes Perfect Visual Effect
| · High Brightness: ≥7000nits | · High Grey Scale: 65536 levels |
| · High Refresh Rate: 2880Hz | · High Contrast: 5000:1 |
SMD Performance and View Angle
Better contrast ratio and viewing performance
Wide viewing angle increasing its value by covering more viewing
Energy Saving Stadium Perimeter
LED Display
1) Using high efficiency IC driver
2) improved PCB design
3) Power conversion efficiency
Backup for Recycle
