Shopping Mall Advertising P2mm HD LED Poster Display Floor Stand
Alone Easy Moving 640*1920mm
LED poster display, is almost the most popular led screen in recent
years. and with slim and fashion outline, 7 color to choose . the
most important is easy for software settings compared with
traditional advertising ,also can show text, pictures, video, and
sound with high resolution,high brightness .
Shopping Mall Advertising P2mm HD LED Poster Display Floor Stand
Alone Easy Moving 640*1920mm
you can put it in your stores and install it by floor standing,
wall mounted, hanging and stacking, even more than 2 screens can
connect freely.
LED Poster is suitable for convention and exhibition center,
shopping center, conference, hall, wedding, performance, airport
station, supermarket. restaurant, movie studio and other occasions.
Feature
1. WiFi / 4G / APP / USB / PC Multiple Communications
2. Advertising publishing remotely & congregated, and audio speaker
Integrated in LPoster.
3. Easy moving, Stand, Hanging, Wall mounted, Multiple Installation
4. Multiple Pitches P2 / P2.5 / P3
Multiple Sizes & Customized Sizes 1920 x 640/4800mm
5. Complete Contents on Multiple Screens Connection
Product specification
| Item | Technical parameter |
Pixel Pitch | 2mm |
Module Resolution | 160*80 dots |
Module Size | 320*160mm |
Pixel configuration | 1R1G1B |
Module Chip | Kinglight/Nationstar |
Driving Method | 1/32Scan |
Physical Density | 250,000 dots/m2 |
LED Encapsulation | SMD1515 |
Module Port | BUH75 |
Module Consumption | ≤16W |
Brightness | 1200 cd/m2 |
Cabinet Dimension | 640*1920mm |
Cabinet External Dimensions | 700*1980*100mm |
Cabinet Resolution | 320*960 dots |
Quantities of module | 2*12 |
Cabinet Flatness | Tolerance of inter pixel ≤0.3mm |
Cabinet Material | Aluminume,Iron |
Cabinet Weight | 38KG |
Option Distance | 2--80M |
Viewing Angle | Horizontal 140° Vertical 120° |
Max. Power consumption | 675W/sqm |
Driving Device | ICN2153IC |
Frame Frequency | 60Hz |
Screen Flatness | Tolerance of cabinets ≤0.6mm |
Refresh Frequency | 1920Hz/3840Hz |
Control Mode | Wifi asynchronization |
Working Environment | Temperature -10℃~60℃ Humidity 10%~70% |
Display Working Voltage | AC110V/220V , 50Hz/60Hz |
Colour temperature | 8500K-11500K |
Communication distance | Network cable: 100m, Multi-model: 500m, Single-model fiber: 20km |
Gray scale | ≥16.7M |
| MTBF | >10,000 hours |
| Support video source | HDMI, CVBS, SDI , DVI etc |
How LED Poster Works - Topology Diagram
Dimension
Packaging
Key Features
