P4 LED Advertising Boards Football Stadium outdoor smd led display
5-400m View Distance
Features
1. High Brightness
More than 6500nits and it can be sawn from long distance.
2. Soft Mask
Soft mask design delivers good protection to the players and also
decreases damage to LEDs.
3. Adjustable Support and Quick Rigging System
Flexible support design makes LED panel lean by multi angles to
cater audience’s needs and quick rigging system design makes the
installation and dismantle easier and faster.
4. Cost Effective LED Display
Energy saving design, help you saving cost.
5. Waterproof and 2 Year Warranty
Water Proof IP43 and 2 year warranty. LED display can work in
all-weather condition very well.
Application:
Large stadium, Waiting room, TV live broadcast, Exhibition hall,
Performing arts center, Entertainment venue, Large-scale art show,
Concert etc.
Product specification
| Product Series | P4 |
| Pixel Pitch | 4mm |
| Pixel Package | SMD2121 |
| LED Configuration | 1R1G1B |
| Pixel Density | 62,500 Pixels/㎡ |
| Module Size | 128mm x 128mm |
| Module Resolution | 32 x 32 dots |
| Suggested Cabinet Size | 640mm x 512mm x 135mm |
| Cabinet Resolution | 160 x 128 dots |
| Cabinet Material | Iron / Aluminum |
| Brightness | ≥ 1200 nits |
| Color Temperature | 3000-12000K |
| Viewing Angle | H-140°/ V-140° |
| Refresh Rate | 960-2880Hz |
| Frame Frenquency | 60Hz |
| Grey Level | 10 bits/ 1024 levels |
| Number of Color | ＞1 billion |
| Maximum Power Consumption | 1000 W/㎡ |
| Average Power Consumption | 400 W/㎡ |
| Input Voltage | AC220±10%, AC110 ±10% |
| Input Frequency | 50-60Hz |
| External Interface | S-video, VGA, DVI, SDI, CVBS, YPrPb, HDMI, etc |
| IP Rating | IP40/IP43 |
Competitive Advantages:
1. Good quality;
2. Good price;
3. Good 24hours service;
4. Promote delivery;
5. Energy-saving;
6. Small order accepted.
Our serrvices
1. Service before sales
On-site inspect
Professional design
Solution confirmation
Training before operation
Software use
Safe operation
Equipments maintenance
Installation debugging
Installation guidance
On-site debugging
Delivery Confirmation
2. After sale service
Quick response
Prompt question resolving
Service tracing
3. Service concept:
Timeliness, considerateness, integrity, satisfaction service.
We are always insisting on our service concept, and proud of the
trust and reputation from our clients.
4. Service Mission
Answer any question; Deal with all the complaint; Prompt customer
service
We had developed our service organization by responding to and
meeting the diverse and demanding needs of customers by service
mission. We had become a cost-effective, highly skilled service
organization.
5. Service Goal:
What you have thought about is what we need to do well; We must and
will do our best to fulfill our promise. We always bear this
service goal in mind. We can't boast the best, yet we will do our
best to free customers from worries. When you get problems, we had
already put forward solutions before you.
