Commercial P5 SMD1921 Outdoor LED Advertising Screen Novastar Cards
LED commercial advertising display screen full color P5 SMD1921
960x960mm Cabinets Novastar cards
Features
1. High uniformity display color.
2. rich in content: can display text, graphics, images, animation,
video information.
3 IP65 grade for high performance waterproof and dustproof
capability.
4. High quality LED chip and high anti-static electricity capacity.
5. Ultra-high brightness, low attenuation, high reliability and
weather ability.
6 excellent viewing angle: both horizontal and vertical have a
large viewing angle, which is suitable for environments with wide
horizontal distribution and large height difference.
Application:Commercial Center, Advertising- Information Publish Board,
Commercial Street, Railway Stations, Airports, Bus Stations,
Subway, Shopping Malls, Supermarkets, Hospitals, Media Centers Etc.
| Specification of P5 Outdoor Fixed LED Display |
| Module |
| Dimention (w*h) | 320mmx160mm | Resolution (w x h) | 64x32 |
| Pixel pitch | 5mm | Pixel Density | 40000 dots/㎡ |
| Pixel Configration | RGB 3-in-1 | LEDs Type | SMD1921 Nationastar Brand |
| Cabinet |
| Dimensions(w* h)(mm) | 960*960mm | Module Quantity(PCS) | 18 |
| Physical Resolution (w x h) | 192*192 | Physical Pixels (total) | 36864 |
| Weight/Cabinet (kg) | 26kg | Material | Magnesium alloy |
| Average Power/㎡(watts) | 300W | Max Power/㎡(watts) | 950W |
| Parameter | Value |
| Brightness | ≥ 5500 cd/㎡ |
| Viewing Angle | Horizontal 140(+70/-70) deg. Vertical 140(+70/-70)deg. |
| Best Viewing Distance | 5-200meters |
| Brightness Control | 256 level |
| Gray scale | 14bits |
| Refresh frequency | ≥ 1920Hz |
| Driving mode | 1/8 scan constant current driving |
| Input power frequency | 50/60 Hertz |
| Input Voltage | AC/220 ～ 240 Volt |
| Blind spot rate | ＜1/10000 |
| Lifetime at 50% brightness | 100000 hours |
| Ingress Protection | IP65/IP54 |
| Operating temperature | ﹣20 ～﹢50 ℃ |
| Operating humidity | 10％ ～ 90％ |
| Control distance | CAT6 cable:＜100 m; Single mode fiber:＜10 km |
| Signal input format | AV, S-Video, VGA, DVI, YPbPr, HDMI, SDI |
| Operating system | Windows (2007/XP/Vista/7/8/10) |
Notes: Specifications are for reference only. Please contact our
salesperson for details. All rights are reserved to AVOE.
