Stadium LED Display P5 1/8 Scan outdoor led video display board
cabinet 960*9600mm
Features:
1, Silicon rubber is chosen for waterproof protector. This material
has high thermostability. We design three-protectors structure for
waterproof.
2, The soft mask is designed with high capacity of impact
resistence. Buffering arc-surface`structure is appled for the mask
shelter It can defuse the impact of football, tennis ball and
players.
3, New structure design. It can meet the needs of rental, perimeter
and fix installation. This multi-functional cabinets makes the new
items easily and conveniently applied in different occasions. And
this structure make the seam of cabinets connection much small.
During hanging.
3, New colour collocation, the color contrast between the black
cabinet body and silver-gray door makes the LED screen much more
elegant
4, Angle adjustable back bracket. User can adjust the best display
viewing angle for audience by the bracket. When rental and fix
installation, the bracket can be folded on the cabinet.
5, Rubber protector on top of cabinet to protect the player from
injury.
6, Aluminum alloy is used for the cabinet to reduce weight, easy to
move from this stadium to that stadium.
Application:
Large stadium, Waiting room, TV live broadcast, Exhibition hall,
Performing arts center, Entertainment venue, Large-scale art show,
Concert etc.
Product specification
| outdoor SMD P5 |
| Resolution/mm | 5 |
| Pixel configuration | 1R1G1B |
| Pixel density/pixels/m² | 40000/m² |
| Module resolution | 64x32 |
| Module size/mm | 320x160 |
| View distance | 5-400m |
| Single point brightness adjust | Can be added |
| Single point color adjust | Can be added |
| White balance brightness | >8000cd/㎡ |
| Color temperature | 6500K-9500K |
| Horizontal view angle | 120(degrees) |
| Vertical view angle | 60(degrees) |
| Signal Process bit | 10 or 16bit |
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 |
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km |
| Driving mode | Constant driving current |
| Scanning mode | 1/8 scan |
| Frame rate | 60Hz |
| Refresh frequency | >1920Hz |
| Control mode | Computer synchronous |
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted 255 steps. No grey loss |
| Out of control point | <1/10000 |
| Working hours | ≥72hours |
| Mean Time Between Failure | >5000hours |
| Life time | 100000hours |
| Life-all-white(brightness halving) | 50000hours |
| Environment temperature range | Operating temperature range: -20-45℃ |
| Maximum power:/㎡ | <1000W |
| Average power:/㎡ | <300W |
| Self-check technology | LED spot self-check, communications check, power check, temperature monitor(need customization) |
| Remote monitoring | Remote supervision and control, record potential fault, send out warning signs to the operators.(need customization) |
| Software environment | Windows (2007/XP/Vista/7/8/10) |
| Luminous point width between centres | Deviation<3% |
| Brightness uniformity | <10% |
| Color uniformity(chromaticity coordinate) | ±0.003 |
| Power supply request | AC85-264V(50Hz-60Hz) |
| Contrast | (1000:1) |
| System protection | Moistureproof,dustproof,high temperature
protection,anti-corrosion,anti-burning,anti-static,anti-vibration |
| Humidity(working) | working:10-95% |
| Humidity(storing) | storing:10-95% |
Competitive Advantages:
1. Good quality;
2. Good price;
3. Good 24hours service;
4. Promote delivery;
5. Energy-saving;
6. Small order accepted.
